CHAIN
CLEVIS & EYE HOOKS
FORGED STEEL QUENCHED AND TEMPERED
CAUTION! NEVER EXCEED WORKING LOAD LIMITS!
WORKING LOAD LIMITS BASED ON 4:1 DESIGN FACTOR
CLEVIS GRAB HOOKS
RATED LOAD
SIZE OF
DIMENSIONS (in.)
WEIGHT
(lbs.)
CHAIN
EACH
HIGHT ALLOY
(in.)
C
E
F
G
(lbs.)
TEST
G 70*
1/4
2600
3150
1.81
0.44
0.38
0.34
0.36
5/16
3900
4700
2.16
0.50
0.44
0.44
0.63
3/8
5400
6600
2.47
0.59
0.47
0.50
1.00
7/16
7200
8750
2.78
0.66
0.56
0.56
1.31
1/2
9200
11300
3.22
0.75
0.63
0.66
2.06
CLEVIS SLIP HOOKS
7
RATED LOAD
SIZE OF
DIMENSIONS (in.)
WEIGHT
(lbs.)
CHAIN
EACH
(in.)
HIGHT TEST
C
E
F
G
(lbs.)
1/4
3900
2.44
0.44
0.38
0.94
0.44
5/16
3900
2.72
0.41
0.44
1.06
0.75
3/8
5400
3.25
0.59
0.47
1.31
1.13
7/16
7200
3.66
0.56
0.56
1.56
2.06
1/2
9200
4.00
0.75
0.63
1.69
2.75
EYE GRAB HOOKS
SIZE OF RATED LOAD (lbs.)
DIMENSIONS (in.)
WEIGHT
CHAIN
EACH
(in.)
HIGHT TEST
C
F
G
(lbs.)
1/4
2600
1.97
0.50
0.35
0.26
5/16
3900
2.25
0.56
0.44
0.45
3/8
5400
2.56
0.66
0.50
0.79
7/16
7200
2.94
0.75
0.56
1.19
1/2
9200
3.38
0.88
0.66
1.75
EYE SLIP HOOKS
SIZE OF RATED LOAD (lbs.)
DIMENSIONS (in.)
WEIGHT
CHAIN
EACH
(in.)
HIGHT TEST
C
F
G
(lbs.)
1/4
2600
2.53
0.50
0.94
0.40
5/16
3900
2.59
0.63
1.06
0.70
3/8
5400
3.31
0.72
1.31
1.00
7/16
7200
3.88
0.81
1.56
1.56
1/2
9200
4.28
0.94
1.69
2.31
